Bose Professional CSP428 8In 2Out DSP Commercial Sound Processor
Pre-owned
Bose Professional CSP428 8In 2Out DSP Commercial Sound Processor is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product overview
Product overview
Bose Professional 8-In 2-Out DSP Commercial Sound Processor
Part Number: CSP-428
In good condition and In full working order
Tested
Included:
1 x Bose Professional CSP-428 8-In 2-Out DSP Commercial Sound Processor
Specification:
General:
Computer Interface Connection: RJ-45 (Ethernet, 10/100 Mbps)
Amplification
Channel Separation (Crosstalk): < -105 dB at +4 dBu, 1 kHz input signal
Dynamic Range: > 115 dB, A-weighted, 20 Hz – 20 kHz, analog through
Frequency Response: 20 Hz – 20 kHz (+0.3 dB/-0.5 dB)
THD+N: < 0.01% at +4 dBu (A-weighted, 20 Hz – 20 kHz)
Audio Inputs, Analog:
Input Channels: 4 (2 unbalanced, summed-mono + 2 balanced, mic/line)
Equivalent Input Noise: < -119 dBu at 64 dB gain (150 Ω input, 22 Hz – 20 kHz)
Input Impedance: 12 kΩ at 1 kHz, with or without phantom power
Phantom Power: 48 V, selectable per input, open circuit, 10 mA maximum per channel, 80 mA maximum across all channels
Connectors: (2) RCA stereo pairs, (1) 3-pin Euroblock, (1) 4-pin Euroblock
Sensitivity Options: -70 dBu, -60 dBu, -50 dBu, 0 dBu, +4 dBu, -10 dBV, selectable phantom power
Maximum Input Level: +24 dBu at 0 dB gain (20 Hz – 20 kHz, THD+N < 0.3%)
Audio Inputs/Outputs, Digital:
Channels: 8 AmpLink out
Type: AmpLink (output)
Connectors: (1) RJ-45 AmpLink out
Audio Outputs, Analog:
Channels: 2 balanced, line
Maximum Output Level: +24 dBu (22 Hz – 20 kHz, THD+N < 0.3%)
Connectors: (2) 3-pin Euroblock
Output Impedance: 66 Ω
Electrical:
Mains Connector: IEC 60320-C14 inlet
AC Power Consumption: < 30 W typical, over all mains voltages (power supply maximum < 45 W)
Mains Voltage: 85–264 VAC, 50/60 Hz
Power Dissipation: 22 W (75 BTU/hr, 19 kcal/hr)
Bose Professional CSP428 8In 2Out DSP Commercial Sound Processor
