TDK Lambda Genesys GEN8 90 8V 90A 720W Programmable Rack 1U DC Power Supply
Pre-owned
TDK Lambda Genesys GEN8 90 8V 90A 720W Programmable Rack 1U DC Power Supply is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product overview
Product overview
Brand: TDK Lambda
Output Power: 720W
Maximum Current Output: 90A
Maximum Voltage Output: 8V
MPN: GEN8-90
Number of Channels/Outputs: 1
Country of Origin: China
TDK-Lambda Genesys GEN8-90 8V 90A 720W Programmable Rack 1U DC Power Supply
Model: GEN8-90
Full Working Order
Tested
Included:
1 x TDK-Lambda Genesys GEN8-90 8V 90A 720W Programmable Rack 1U DC Power Supply
1 x Rack Ears
1 x DC Output Cover
Specification:
Manufacturer: TDK-Lambda:
Model: GEN8-90
Series: Genesys
Output Voltage: 0-8 V DC
Output Current: 0-90 A:
Output Power: 720 W
Load Regulation: 2.8 mV: Line Regulation: 2.8 mV
Digital Interfaces: RS-232 / RS-485 built in, LAN (LXI Class C) option fitted Analogue Programming: 0-5 V / 0-10 V, or 0-5 kOhm / 0-10 kOhm
Protection: OVP (0.5-10 V)
Series Operation: Up to 2 units with external diodes Daisy Chain: Up to 31 units on RS-485
Memory: Last-setting memory, no battery backup required Remote Sense: 1 V compensation per line
AC Input: 85-265 V AC continuous, 47-63 Hz, 10.5 A at 100 V / 5 A at 200 V Power Factor: 0.99 with active correction
Efficiency: 77% at 100 V AC, 80% at 200 V AC: Hold-up Time: More than 20 ms at 100 V AC, full load
Operating Temperature: 0-50 C at 100% load: Dimensions (W x H x D): 422.8 x 43.6 x 432.8 mm
Form Factor: 1U full-rack, 19-inch mountable
AC Connector: IEC320 inlet
TDK Lambda Genesys GEN8 90 8V 90A 720W Programmable Rack 1U DC Powe...
