Extron DA2 HD 4K PLUS 60 1607 01 2 Output 4K / 60 HDMI Distribution Amplifier
Extron DA2 HD 4K PLUS 60 1607 01 2 Output 4K / 60 HDMI Distribution Amplifier is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product overview
Product overview
Number/signal type: 1 HDMI, embedded
Connector: 1 female HDMI type A
Maximum data rate: 18.0 Gbps
Color bit depth: 8, 10, or 12 bits per color
Ultra Wide: 2560x1080, 3440x1440, 3840x1080, 3840x1440, 3840x1600
Frame rate: 24, 25, 30, 50, or 60 fps
Formats: RGB and YCbCr digital video
Color bit depth:: 8, 10, or 12 bits — subject to the max data rate
Standards: DVI 1.0*, HDMI 2.0b, HDCP 2.3, HDCP 1.x
Frame rate1: 24, 25, 30, 50, or 60 fps
Max. video data rate: 18.0 Gbps (6 Gbps per color)
Number of Outputs: 02
Brand: Extron
Signal Type: HDMI 2.0b, HDCP 1.4 and 2.3
Type: Distribution Amplifier
SMPTE: Up to 1080p @ 240 Hz or 4K @ 60 Hz (4:4:4 subsampling)
VESA: 640x480 to 4096x2160
HDR: HDR10, HDR10+, and Dolby Vision
Number of Inputs: 01
Model: DA2 HD 4K PLUS
Connectivity: HDMI
Chroma sampling: 4:4:4, 4:2:2, or 4:2:0
Features: Supports computer and video resolutions up to 4K/60 @ 4:4:4,HDCP 2.3 compliant,Automatic input cable equalization,Key Minder® continuously verifies HDCP compliance,EDID Minder® automatically manages EDID communication between con
- 1 x Extron DA2 HD 4K PLUS 60-1607-01 2 Output 4K / 60 HDMI Distribution Amplifier
- 1 x Extron AC Power Adapter
- Supports computer and video resolutions up to 4K/60 @ 4:4:4
- Supported HDMI 2.0b specification features include data rates up to 18 Gbps, HDR, Deep Color up to 12-bit, 3D, HD lossless audio formats, and CEC control
- HDCP 2.3 compliant
- Automatic input cable equalization
- EDID Minder® automatically manages EDID communication between connected devices
- Key Minder® continuously verifies HDCP compliance
Extron DA2 HD 4K PLUS 60 1607 01 2 Output 4K / 60 HDMI Distribution...
